Description
Water pressure reducing valve 1/2” F-F with pressure gauge – MALGORANI Description:
The Malgorani 1/2 female-female water pressure reducing valve with pressure gauge connection is a hydraulic device designed to regulate and stabilize water pressure in domestic and industrial systems, protecting pipes, taps and sensitive equipment from harmful overpressure. Manufactured with high-quality materials Made in Italy and based on the long-standing experience of Rubinetteria Malgorani Pietro SRL, it ensures reliable and long-lasting performance.
Thanks to its design with female threaded connections according to ISO 228 standard, this reducer can be easily installed on 1/2 pipelines, while the 1/4 pressure gauge connection allows the installation of a pressure gauge (included or optional depending on the version) to monitor inlet and outlet pressure in real time and verify its regulating efficiency.
Features:
Connections: 1/2 F-F threaded ISO 228, compatible with standard hydraulic systems.
Material: corrosion and wear resistant brass body.
Type: direct action pressure reducing valve with pressure compensation system.
Maximum working pressure: up to 25 bar (PN25 series), suitable for domestic and commercial installations.
Outlet pressure adjustment range: typically from 0.5 to 6 bar, factory pre-set around 3 bar.
Maximum operating temperature: approx. 80 °C, suitable for cold and domestic hot water systems.
Pressure gauge connection: 1/4 port for a pressure gauge (usually 010 bar range).
Product code: 146.12.G+119/10
