Description
The metal D-SUB DB25 cable connector (male) with screw cover is designed for terminating multi-core cables and creating a removable connection in applications with a DB25 interface. The screw/nut design allows for a solid mechanical locking of the connector and cable strain relief.
Technical specifications
Connector type: D-SUB DB25
Design: wired, metal body/cover
Gender: male (male)
Number of pins: 25
Contact arrangement: 2 rows
Cover mounting: screw-on
Mechanical locking in connection: screws/nuts
Cable grommets: 4 pcs (for diameters 5 mm, 6 mm, 7.5 mm, 8.5 mm)
Dimensions (according to the picture): approx. 57 mm (width), 56 mm (length), 16 mm (height)
Functions and features
Metal cover for increased mechanical resistance during cable installation
Screw-on design allows for repeated opening and service intervention
Interchangeable grommets for adapting cable diameter and basic strain relief
Screws/nuts for tight tightening of the connector to the mating piece and limiting spontaneous loosening
Ideal for
Production and repair of cables with DB25 interface
Industrial equipment, measuring technology and control systems
Service and laboratory cabling where mechanical connector locking is required
Package contents
1× D-SUB DB25 connector (male) with screw-on metal cover
4× cable gland (5 mm, 6 mm, 7.5 mm, 8.5 mm)
2× screw
2× nuts
Why choose this product?
Standard DB25 design for compatibility with common counterparts
Metal screw cover suitable for installations with higher demands on mechanical resistance
Possibility to choose the bushing according to the cable diameter
Mechanical locking of the connector using screws/nuts
Installation and operating instructions
Before installation, select a grommet according to the cable diameter and fit it into the housing outlet.
Shorten the wires to the required length, connect them to the connector contacts and check the correct signal sequence.
After connection, close the cover, tighten the screws and check that the cable is not mechanically stressed in the cover.
When connecting to the mating piece, use screws/nuts to firmly secure the connector.
Safety notice
The product is intended for signal and data connection; disconnect the device from power before handling.
Make sure to connect the pins correctly according to the interface used to avoid damaging the connected devices.
Avoid short circuits between conductors and contacts with conductive parts of the housing.
