Description
Shin-Etsu X-23-7921-5 Thermally Conductive Paste is a thermal interface (TIM) designed to fill micro-imperfections between a heat source and a heat sink. It reduces contact thermal resistance, increases heat transfer efficiency, and is suitable for long-term operation in electronic applications. The 5 g package option is designed for service, prototyping, and routine assembly.
Technical specifications
Type: thermal paste
Model: X-23-7921-5
Manufacturer/series: Shin-Etsu
Color: gray
Package weight: 5 g
Thermal conductivity: 6.0 W/mK
Thermal resistance: 5.8 mm2K/W
Density (specific gravity): 2.8 g/cm3
Viscosity: 360 Pa.s
Evaporation (volatility): 0.44 (150°C/24 h)
Oil separation rate: 0.05 (150°C/24 h)
Working temperature: -50 to +120 °C
Electrical insulation property: insulation coefficient < 100 V / 0.25 mm
Functions and features
Fills air gaps between component and heat sink and increases contact area
Promotes efficient heat transfer from electronic components to the heat sink
Non-curing for service and long-term use
Non-corrosive to common substrates in electronics
Good thixotropy for easy application and even spreading
Ideal for
CPU, GPU and power semiconductors
LED modules and power LED applications with heat sink
Power converters, power supplies and industrial electronics
Service replacement of thermal paste and prototype assembly
Package contents
1x Shin-Etsu X-23-7921-5 Thermal paste, 5 g (syringe)
Why choose this product?
Defined parameters for thermal interface design (thermal conductivity, thermal resistance, viscosity)
Stable properties within the specified operating temperature range
Suitable for applications where low oil separation rates and low volatility are required
Installation and operating instructions
Before application, clean the contact surfaces from dust, grease and remnants of the original material.
Apply a thin, continuous layer and use the pressure of the cooler to ensure even distribution
Remove excess material with a soft cloth.
Store in a closed container; after opening, consume within a reasonable time according to storage and handling conditions.
Safety notice
Avoid contact with eyes and prolonged contact with skin; wash hands after handling.
Keep out of reach of children.
Do not use on surfaces where contamination of optical or contact surfaces could occur.
